Using Zabbix to monitor lxc / lxd containers

published on

Note: This article is based on the work found at https://github.com/kvaps/zabbix-linux-container-template that has been done by others. This article simply updates that work to for Zabbix 7. However, credit should go to the original author.

Introduction

Zabbix doesn't collect memory information from lxc  containers properly and so the following 'intergration' or 'workaround' has been put together to fix this.

Implement the fix

First, login to the container you wish to monitor and create a Zabbix container configuration file in the agent folder (presuming you are using Zabbix agent and not Zabbix agent v2) by running sudo nano /etc/zabbix/zabbix_agentd.d/zabbix_container.conf.

Add the following into this file:

UserParameter=ct.memory.size[*],free -b | awk 'NR==2 {total=$ 2; used=($ 3+$ 5); pused=(($ 3+$ 5)*100/$ 2); free=$ 4; pfree=($ 4*100/$ 2); shared=$ 5; buffers=$ 6; cached=$ 6; available=$ 7; pavailable=($ 7*100/$ 2); if("$1" == "") {printf("%.0f", total )} else {printf("%.0f", $1 "" )} }'
UserParameter=ct.swap.size[*],free -b | awk 'NR==3 {total=$ 2; used=$ 3; free=$ 4; pfree=($ 4*100/$ 2); pused=($ 3*100/$ 2); if("$1" == "") {printf("%.0f", free )} else {printf("%.0f", $1 "" )} }'
UserParameter=ct.cpu.load[*],cut -d" " -f1-3 /proc/loadavg | awk -F'[, ]+' '{avg1=$(NF-2); avg5=$(NF-1); avg15=$(NF)}{print $2/'$(nproc)'}'
UserParameter=ct.uptime,cut -d"." -f1 /proc/uptime

Now restart the Zabbix agent with sudo systemctl restart zabbix-agent.

Update the Zabbix GUI

In the Zabbix GUI select Data Collection then Templates. Click on Linux by Zabbix agent (for passive checks) or Linux by Zabbix agent active (for active checks) and click on Clone.

Once you've given it a new name and clicked on Add you need to find the Items section of the new template.

  • Find any reference to vm.memory.size and change them to ct.memory.size.
  • Find any reference to system.cpu.load and change them to ct.cpu.load.
  • Find any reference to system.swap.size and change them to ct.swap.size. You also need to remove the comma inside the square brackets too.

Once you've done all of that select Data Collection from the menu on the far left  then choose Hosts. Click on the name of a host which is a container. Under the templates section unlink and clear the Linux by Zabbix agent template and then attach your new template you created earlier.

Finally click on Update and enjoy your container reporting the correct values back to Zabbix!

Conclusion

This is just one of the many integrations which you can explore and work with that can be found at https://www.zabbix.com/integrations.
